K30160 Kusing Diesel Generator

Technical Parameters
Model K30160
Phase 3 Phase
Power Factor 0.8cosØ
Frequency 50HZ 60HZ
Speed RPM 1500 1800
Max. Power KVA 22.0 24.8
KW 17.6 19.8
Rated Power KVA 20.0 22.5
KW 16.0 18.0
Rated Voltage V 400 400
Rated Current A 29 32
Fuel Consumption G/KW.H ≤230
Generator Controller Auto Multi-function
Engine Model. YSD490
Alternator TCU188A
Clinder No. 4
Starting System Electric Start
Cooling Method Water-cooling
Protection Grade IP21-IP23
Insulation Class H
Size (MM) Silent Type 2250*950*1100
Open Type 1530*700*950
Optional ATS (auto transfer switch)

Kusing is a leading industrial diesel generator manufacturer, K30160 Kusing engine powered 16KW 50HZ and 18KW 60HZ diesel generator supplier, there are a wide range of diesel gensets with power ranging from 10KVA to 2000KVA, such as Cummins engine powered generator, Perkins engine powered generator, Lovol engine powered generator, etc. We have years of experience in designing and manufacturing industrial generators, each genset is tested to ensure quality, Kusing company provides quality diesel gensets as well as diesel power solutions for customers.
